  HardyDrBefore_01.JPG - Hardy Dr "before"Streetscape project completed early 2015. This is Hardy between 12th St and 12th Pl. BL-stripe-to-BL-stripe was ~ 29' -- that is 10' / 9' /10' lanes; curb-to-curb is just shy of 40' meaning BL gross width was about 5' each (including gutter pans). Also, south of 13th St, Hardy widens quite a bit to ~ 46' -- as usual, the extra width goes to the "car lanes" and BL stays cramped. These real dimensions seem to be a bit different that the claimed existing dimensions here http://www.tempe.gov/home/showdocument?id=8822 E.g. they claim the BLs are 6'. and 6'4". No way. There's a notation on that document that states measurement of road width is "to back of curb"; whatever that means... I think it means they claim the width of the curb is in the BL!






Hardy Dr "before"Streetscape project completed early 2015. This is Hardy between 12th St and 12th Pl. BL-stripe-to-BL-stripe was ~ 29' -- that is 10' / 9' /10' lanes; curb-to-curb is just shy of 40' meaning BL gross width was about 5' each (including gutter pans). Also, south of 13th St, Hardy widens quite a bit to ~ 46' -- as usual, the extra width goes to the "car lanes" and BL stays cramped. These real dimensions seem to be a bit different that the claimed existing dimensions here http://www.tempe.gov/home/showdocument?id=8822 E.g. they claim the BLs are 6'. and 6'4". No way. There's a notation on that document that states measurement of road width is "to back of curb"; whatever that means... I think it means they claim the width of the curb is in the BL! Download Original Image
